Flangeless Fittings
Flangeless Fittings eliminate the need to flange tubing. This removable and reusable system provides several benefits such as providing flangeless chromatography fittings for observing mixtures and solvents. Flangeless Fittings are easy to use. Just slip the nut and ferrule over the tubing and finger tighten the assembly into your receiving port. Our Flangeless Fitting require minimal downtime because component replacement is quick, taking only a few seconds. Flangeless Fittings systems typically require only one new ferrule at minimal cost...
More Information >
Flangeless Fittings eliminate the need to flange tubing. This removable and reusable system...
More Information >
total selected
Clear selection
1.8mm OD Ferrule, Flangeless
P-342 / -
- For use with 1.8mm OD tubing mating with flat bottom ports
- Green ETFE material
- Recommended for pressures up to 500 psi (34 bar)
- 1 per pack
1.8mm OD Ferrule, Flangeless
P-342X / -
- For use with 1.8mm OD tubing mating with flat bottom ports
- Green ETFE material
- Recommended for pressures up to 500 psi (34 bar)
- 10 per pack
1/16" OD Ferrule, Flangeless
P-200NX / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Natural ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 10 per pack
1/16" OD Ferrule, Flangeless
P-200N / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Natural ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
1/16" OD Ferrule, Flangeless
P-200R / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Red ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
1/16" OD Ferrule, Flangeless
P-221 / -
- For use with 1/16" OD tubing mating with flat bottom ports
- Natural polypropylene material
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
1/16" OD Ferrule, Flangeless
P-200 / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Blue ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
1/16" OD Ferrule, Flangeless
P-200X / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Blue ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 10 per pack
1/16" OD Ferrule, Flangeless Short
P-240 / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Natural ETFE material
- Reduced length for shorter depth ports
- Recommended for pressures up to 2500 psi (172 bar)
- 1 per pack
1/16" OD Fitting, Flangeless
XP-286 / -
- For use with 1/16" OD tubing mating with a 1/4-28 port
- Headless nut for space limited applications
- Natural PPS nut, blue ETFE ferrule
- Include P-200 Flangeless ferrule
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
Flangeless Fittings
Flangeless Fittings eliminate the need to flange tubing. This removable and reusable system provides several benefits such as providing flangeless chromatography fittings for observing mixtures and solvents. Flangeless Fittings are easy to use. Just slip the nut and ferrule over the tubing and finger tighten the assembly into your receiving port. Our Flangeless Fitting require minimal downtime because component replacement is quick, taking only a few seconds. Flangeless Fittings systems typically require only one new ferrule at minimal cost when
repairing a connection.
