Fittings
IDEX Health & Science offers a wide selection of fittings, connections, and tubing to meet your fluidic system requirements. From high pressure HPLC / UHPLC to low-pressure fittings, we offer PEEK, stainless steel, finger tight, micro, torque limiting, flanged, flangeless, super flangeless, coned, flat bottom, and peek tubing fittings, peek connectors and more. Learn more in our Fittings 101 guide.
A “fitting” refers to a complete... More Information >
IDEX Health & Science offers a wide selection of fittings, connections, and tubing to meet... More Information >
total selected
Clear selection
1.8mm OD Ferrule, Flangeless
P-342X / -
- For use with 1.8mm OD tubing mating with flat bottom ports
- Green ETFE material
- Recommended for pressures up to 500 psi (34 bar)
- 10 per pack
1.8mm OD Ferrule, Flangeless
P-342 / -
- For use with 1.8mm OD tubing mating with flat bottom ports
- Green ETFE material
- Recommended for pressures up to 500 psi (34 bar)
- 1 per pack
1/16" OD BioTight Ferrule
LP-062 / -
- For use with 1/16" OD tubing mating to 1/4-28 flat bottom ports
- All PEEK Super Flangeless style fitting system
- True finger tight connection
- For use with LP-336 BioTight fitting
- Black and Natural PEEK ferrule material
- Recommended for pressures up to 200 psi (14 bar)
- 1 piece per pack
1/16" OD Ferrule, Flangeless
P-200NX / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Natural ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 10 per pack
1/16" OD Ferrule, Flangeless
P-200X / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Blue ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 10 per pack
1/16" OD Ferrule, Flangeless
P-200 / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Blue ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
1/16" OD Ferrule, Flangeless
P-221 / -
- For use with 1/16" OD tubing mating with flat bottom ports
- Natural polypropylene material
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
1/16" OD Ferrule, Flangeless
P-200N / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Natural ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
1/16" OD Ferrule, Flangeless
P-200R / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Red ETFE material
- Recommended for pressures up to 2000 psi (138 bar)
- 1 per pack
1/16" OD Ferrule, Flangeless Short
P-240 / -
- For use with 1/16” OD tubing mating with flat bottom ports
- Natural ETFE material
- Reduced length for shorter depth ports
- Recommended for pressures up to 2500 psi (172 bar)
- 1 per pack
Fittings
IDEX Health & Science offers a wide selection of fittings, connections, and tubing to meet your fluidic system requirements. From high pressure HPLC / UHPLC to low-pressure fittings, we offer PEEK, stainless steel, finger tight, micro, torque limiting, flanged, flangeless, super flangeless, coned, flat bottom, and peek tubing fittings, peek connectors and more. Learn more in our Fittings 101 guide.
A “fitting” refers to a complete product ready to assemble and connect tubing into a part. This could be a one-piece connector or a nut and ferrule packaged together. A “Nut” indicates the male or female threaded product sold separately, and a “Ferrule” is sold separately when indicated in the description. For your convenience we ship most Fittings and Ferrules in 10-packs, however, you may order individual pieces. We are dedicated to providing the most reliable, proven fittings on the market for use in biotech and lab markets. We have implemented more stringent testing protocols and a generous safety margin to our ratings to ensure your safety.
