Our Flangeless Fittings are designed to include both a nut and ferrule for your convenience. Flangeless fitting are dependable, easy to use and easy to replace. It has a 1/4-28 Flat-Bottom port configuration and is for 1/8 OD tubing. Our Fitting System comes in blue and includes the P-300 ferrule.
Looking for a CAD file for this product? Request a CAD now!
Looking to design this product into your instrument? Fill out this form for more information.
-
EachUS Domestic pricing – contact your local distributor for other currency list prices
-
8.99 USD EachUS Domestic pricing – contact your local distributor for other currency list prices
-
-
0.000.00 -
-
- Notify me when available
| Thread Port Design | 1/4-28 Flat-Bottom |
|---|---|
| Tubing OD | 1/8 inch |
| Material | PEEK, ETFE |
| Pressure Rating | 500 psi (34 bar) |
| Fitting Type | Nut, Ferrule |
| Head Style | Standard Knurl |
total selected
Clear selection
Select all 1 products from all pages.
1/8" OD Ferrule, Flangeless
P-300X / 0
- For use with 1/8" OD tubing mating with flat bottom ports
- Yellow ETFE material
- Recommended for pressures up to 500 psi (34 bar)
- 10 per pack
1 of 1
| Topic | Description |
| Flangeless Fitting System Connection Guide | Use this guide to connect your fluidic path. |
total selected
Clear selection
Select all 1 products from all pages.
1/8" OD Ferrule, Flangeless
P-300X / 0
- For use with 1/8" OD tubing mating with flat bottom ports
- Yellow ETFE material
- Recommended for pressures up to 500 psi (34 bar)
- 10 per pack
1 of 1
| Topic | Description |
| Flangeless Fitting System Connection Guide | Use this guide to connect your fluidic path. |
