558/15 nm BrightLine® single-band bandpass filter

Semrock Part Number: FF01-558/15-25

IDEX Part Number: FL-440121  /

Semrock

Individual fluorescence bandpass filters that have been optimized for use in a variety of fluorescence instruments. All thin-film, hard-coated construction for unsurpassed performance and reliability.

  • Price Not Available.
  • Each
    US Domestic pricing – contact your local distributor for other currency list prices
  • Price Not Available.
  • 340.03 USD Each
    US Domestic pricing – contact your local distributor for other currency list prices
  • 0.00
    0.00
  • Notify me when available
Add to List Add to List
Optical Specifications Value
Transmission Band 1 Tavg > 93% 550 – 560 nm
Transmission Band 2 Tabs > 90% 552 – 558 nm
Transmission Band 3 Tavg > 93% 556 – 565 nm
Transmission Band 4 Tabs > 90% 558 – 564 nm
Blocking Band 1   ODavg > 4 200 -­ 275 nm (Design specification - measurements are noise-floor limited)
Blocking Band 2 ODavg > 4 275 – 421 nm
Blocking Band 3   ODavg > 8 421 – 537 nm (Design specification - measurements are noise-floor limited)
Blocking Band 4 OD > 3.5 543 nm
Blocking Band 5 OD > 3.5 572 nm
Blocking Band 6   ODavg > 8 557 – 750 nm (Design specification - measurements are noise-floor limited)
Blocking Band 7 ODavg > 4 750 – 925 nm
Blocking Band 8 ODavg > 2 925 – 1100 nm
Center Wavelength 1 557.5 nm
Guaranteed Minimum Bandwidth 1 15 nm
FWHM Bandwidth 1 (nominal) 20.3 nm
General Filter Specifications Value
Angle of Incidence 0 ± 5 degrees
Cone Half-angle 7 degrees
Optical Damage Rating Testing has proven to show no signs of degradation when exposed to at least 6.0 W of power from an unfiltered xenon arc lamp over a 25 mm diameter (corresponding to 1.2 W/cm2) for over 500 hours.
Physical Filter Specifications   Value
Transverse Dimensions (diameter) 25 mm
Transverse Tolerance + 0.0 / - 0.1 mm
Filter Thickness (mounted) 5.0 mm
Filter Thickness Tolerance (mounted) ± 0.1 mm
Clear Aperture ≥ 21 mm
Scratch-Dig 60-40
Filter Thickness (unmounted) 2.0 mm
Filter Thickness Tolerance (unmounted) ± 0.1 mm
Exciter/Emitter Orientation Arrow on ring indicates preferred direction of propagation of light.
