Bulkhead Union Assembly Flat-Bottom .040 thru hole

IDEX Part Number: U-453  /

Our Stainless Steel Bulkhead Union Assembly are precision machined from 316 stainless steel. Our mechanically strong and reliable union offers true zero dead volume (ZDV) allowing tubing to be joined without interrupting the fluidic path. The bulkhead union is manufactured for easily plumbing tubing through equipment housing. The adapter has a 0.040" thru-hole and has a 1/4-28 Flat-Bottom thread port configuration.

Looking for a CAD file for this product? Request a CAD now!

Global and domestic verified OEM partners may be eligible to receive discounted pricing. Please reach out through this form to see if you qualify.

  • Price Not Available.
  • Each
    US Domestic pricing – contact your local distributor for other currency list prices
  • Price Not Available.
  • 97.67 USD Each
    US Domestic pricing – contact your local distributor for other currency list prices
  • 0.00
    0.00
  • Notify me when available
For Tubing OD (in) 1/16
Material Stainless Steel
Thread Port Configuration Flat-Bottom 1/4-28
Thru hole (in) 0.04
Thru hole (mm) 1

Specifications
