This filter set is designed for use with Texas Red, Alexa Fluor 594, ATTO 590 and works well with other red fluorophores. The AvantTM filter set family delivers significant increases in fluorescence performance for small Stokes Shift fluorophores compared to standard filter sets. Steep spectral edges and high complementary OD blocking maximize signal while maintaining low bleedthrough and high signal to noise ratio. The new Precise Edge Placement capability ensures every filter set delivers consistent performance.
-
EachUS Domestic pricing – contact your local distributor for other currency list prices
-
1,121.58 USD EachUS Domestic pricing – contact your local distributor for other currency list prices
-
-
0.000.00 -
-
- Notify me when available
Filter set mounted in microscope holders/cubes found below in related products section.
Set Components
AF01-585/29-25FL-429643
Each
• Tavg > 93% 570 – 599 nm
• Center Wavelength of 585 nm and GMBW of 29 nm • FWHM of 34.5 nm |
FL-429643 |
|
.tmb-smartercom.png?Culture=en&sfvrsn=33926828_1)
AF01-626/35-25FL-429645
Each
• Tavg > 93% 609 – 644 nm
• Center Wavelength of 626 nm and GMBW of 35 nm • FWHM of 38 nm |
FL-429645 |
|
AF604-Di01-25x36FL-429647
Each
Custom sizing delivery confirmed ARO (sizing fee applies). |
FL-429647 |
total selected
Clear selection
Select all 9 products from all pages.
Avant-TxRed-NTE
S-431324 / 0
Avant™ single-band filter set, optimized for Texas Red™, Alexa Fluor 594 and other like fluorophores
High-performance filter set for high-end applications. Ideal for use with: Texas Red™, Alexa Fluor 594, and red fluorophores
Avant-TxRed-NQF
S-431325 / 0
Avant™ single-band filter set, optimized for Texas Red™, Alexa Fluor 594 and other like fluorophores
High-performance filter set for high-end applications. Ideal for use with: Texas Red™, Alexa Fluor 594, and red fluorophores
Avant-TxRed-ZHE
S-431326 / 0
Avant™ single-band filter set, optimized for Texas Red™, Alexa Fluor 594 and other like fluorophores
High-performance filter set for high-end applications. Ideal for use with: Texas Red™, Alexa Fluor 594, and red fluorophores
Avant-TxRed-OMF
S-431327 / 0
Avant™ single-band filter set, optimized for Texas Red™, Alexa Fluor 594 and other like fluorophores
High-performance filter set for high-end applications. Ideal for use with: Texas Red™, Alexa Fluor 594, and red fluorophores
Avant-TxRed-OFF
S-431328 / 0
Avant™ single-band filter set, optimized for Texas Red™, Alexa Fluor 594 and other like fluorophores
High-performance filter set for high-end applications. Ideal for use with: Texas Red™, Alexa Fluor 594, and red fluorophores
Avant-TxRed-ZHE-ZERO
S-434102 / 0
Avant™ single-band filter set, optimized for Cy7™, Alexa Fluor 750 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy7™, Alexa Fluor 750, and NIR fluorophores
Avant-TxRed-OMF-ZERO
S-434159 / 0
Avant™ single-band filter set, optimized for Texas Red™, Alexa Fluor 594 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Texas Red™, Alexa Fluor 594, and red fluorophores
Avant-TxRed-NTE-ZERO
S-434164 / 0
Avant™ single-band filter set, optimized for Texas Red™, Alexa Fluor 594 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Texas Red™, Alexa Fluor 594, and red fluorophores
Avant-TxRed-OFF-ZERO
S-434671 / 0
Avant™ single-band filter set, optimized for Texas Red™, Alexa Fluor 594 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Texas Red™, Alexa Fluor 594, and red fluorophores
1 of 1
| Topic | Description |
| Cleaning Optical Filters | Instructions for cleaning hard coated optical filters |
| Filter Reliability | Compares the performance and reliability of hard coated filters to traditional soft-coated filters and provides information about the testing standards for Semrock filters |
| Working with Optical Density | Tables to describe the relationship between OD and transmission with tips for quickly calculating OD |
| Topic | Description |
| Cleaning Optical Filters | Instructions for cleaning hard coated optical filters |
| Filter Reliability | Compares the performance and reliability of hard coated filters to traditional soft-coated filters and provides information about the testing standards for Semrock filters |
| Working with Optical Density | Tables to describe the relationship between OD and transmission with tips for quickly calculating OD |
| What is Pixel Shift, and how does the Semrock ZERO™ option help? | Why Pixel Shift degrades multicolor fluorescence imaging performance, and how the ZERO™ option mitigates this for Avant and BrightLine filter sets. |
Optimized – Filter set is specifically optimized for that fluorophore.
Compatible – Should result in nearly ideal performance in most situations.
Acceptable – Actual performance is dependent on specific experimental conditions.
| Fluorophore | Peak Excitation Wavelength(nm) | Peak Emission Wavelength(nm) | Compatibility | Display on Plot above |
|---|---|---|---|---|
| Alexa Fluor® 594 | 590 | 618 |
|
|
| ATTO 590 | 594 | 624 |
|
|
| Texas Red® | 592 | 614 |
|
| Link | Description |
| Request a Drawing | Looking for an optical filter drawing file for this product? Request one now! |
| Request Custom Optical Filters | Contact us today to start a conversation about custom optical filters. |
| Access Optical Filter Warranty | Find our warranty in our Terms & Conditions of Sale. |
| Semrock Optical Filters RoHS Certificate | RoHS, stands for Restriction of Hazardous Substances. The current RoHS Directive currently restricts the use of ten substances. |
| Semrock Optical Filters REACH Certificate | REACH is a regulation of the European Union, adopted to improve the protection of human health and the environment from the risks that can be posed by chemicals, while enhancing the competitiveness of the EU chemicals industry. |
| Download Optical Filters 101 Guide | Find an in-depth overview of optical filter principles, specifications, and applications. Request a digital copy of this guide now. |
| Request Clean Filter Checklist Poster | Looking to clean your optical filters? Need instructions? Request a printed copy of our Clean Filter Checklist Poster. |
