This filter set is designed for use with Cy5™ and Alexa Fluor 647 and works well with ATTO 643, ATTO 647 and other Red fluorophores. The Avant™ filter set family delivers significant increases in fluorescence performance for small Stokes Shift fluorophores compared to standard filter sets. Steep spectral edges and high complementary OD blocking maximize signal while maintaining low bleedthrough and high signal to noise ratio. The new Precise Edge Placement capability ensures every filter set delivers consistent performance.
-
EachUS Domestic pricing – contact your local distributor for other currency list prices
-
1,121.58 USD EachUS Domestic pricing – contact your local distributor for other currency list prices
-
-
0.000.00 -
-
- Notify me when available
We now offer LFOV (large field of view) cube sets compatible with Nikon Eclipse Ti2 microscopes. Please contact us for more information.
Set Components
.tmb-smartercom.png?Culture=en&sfvrsn=d5882acf_1)
AF01-633/40-25FL-433899
Each
• Tavg > 93% 613 – 653 nm
• Center Wavelength of 633 nm and GMBW of 40 nm • FWHM of 43.6 nm |
FL-433899 |
|
AF01-684/40-25FL-433900
Each
• Tavg > 93% 664 – 704 nm
• Center Wavelength of 684 nm and GMBW of 40 nm • FWHM of 44.7 nm |
FL-433900 |
|
.tmb-smartercom.png?Culture=en&sfvrsn=f2fddda0_1)
AF659-Di01-25x36FL-433901
Each
Custom sizing delivery confirmed ARO (sizing fee applies). |
FL-433901 |
total selected
Clear selection
Select all 11 products from all pages.
.tmb-smartercom.png?Culture=en&sfvrsn=877fac26_1)
Avant-Cy5-ZHE-ZERO
S-434112 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
Avant-Cy5-NTE-ZERO
S-434165 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
Avant-Cy5-NTE
S-434624 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
Avant-Cy5-NQF
S-434626 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
Avant-Cy5-ZHE
S-434627 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
Avant-Cy5-OMF
S-434628 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
Avant-Cy5-OFF
S-434629 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
Avant-Cy5-OMF-ZERO
S-434630 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
Avant-Cy5-OFF-ZERO
S-434639 / 0
Avant™ single-band filter set, optimized for Cy5™, Alexa Fluor 647 ATTO 643, ATTO 647, and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy5™, Alexa Fluor 647, and NIR fluorophores
| Topic | Description |
| Cleaning Optical Filters | Instructions for cleaning hard coated optical filters |
| Filter Reliability | Compares the performance and reliability of hard coated filters to traditional soft-coated filters and provides information about the testing standards for Semrock filters |
| Working with Optical Density | Tables to describe the relationship between OD and transmission with tips for quickly calculating OD |
| What is Pixel Shift, and how does the Semrock ZERO™ option help? | Why Pixel Shift degrades multicolor fluorescence imaging performance, and how the ZERO™ option mitigates this for Avant and BrightLine filter sets. |
| Link | Description |
| Request a Drawing | Looking for an optical filter drawing file for this product? Request one now! |
| Request Custom Optical Filters | Contact us today to start a conversation about custom optical filters. |
| Access Optical Filter Warranty | Find our warranty in our Terms & Conditions of Sale. |
| Semrock Optical Filters RoHS Certificate | RoHS, stands for Restriction of Hazardous Substances. The current RoHS Directive currently restricts the use of ten substances. |
| Semrock Optical Filters REACH Certificate | REACH is a regulation of the European Union, adopted to improve the protection of human health and the environment from the risks that can be posed by chemicals, while enhancing the competitiveness of the EU chemicals industry. |
| Download Optical Filters 101 Guide | Find an in-depth overview of optical filter principles, specifications, and applications. Request a digital copy of this guide now. |
| Request Clean Filter Checklist Poster | Looking to clean your optical filters? Need instructions? Request a printed copy of our Clean Filter Checklist Poster. |
Optimized – Filter set is specifically optimized for that fluorophore.
Compatible – Should result in nearly ideal performance in most situations.
Acceptable – Actual performance is dependent on specific experimental conditions.
| Fluorophore | Peak Excitation Wavelength(nm) | Peak Emission Wavelength(nm) | Compatibility | Display on Plot above |
|---|---|---|---|---|
| Alexa Fluor® 647 | 653 | 668 |
|
|
| Cy5™ | 649 | 666 |
|
