Avant single-band filter set, optimized for Cy3™, Alexa Fluor 555, ATTO 550 and other like fluorophores

Semrock Part Number: Avant-Cy3-000

IDEX Part Number: S-429490  /

Semrock


This filter set is designed for use with Cy3™ and Alexa Fluor 555 and works well with ATTO 550 and other orange fluorophores. The Avant™ filter set family delivers significant increases in fluorescence performance for small Stokes Shift fluorophores compared to standard filter sets. Steep spectral edges and high complementary OD blocking maximize signal while maintaining low bleedthrough and high signal to noise ratio. The new Precise Edge Placement capability ensures every filter set delivers consistent performance.
  • Price Not Available.
  • Each
    US Domestic pricing – contact your local distributor for other currency list prices
  • Price Not Available.
  • 1,116.05 USD Each
    US Domestic pricing – contact your local distributor for other currency list prices
  • 0.00
    0.00
  • Notify me when available
We now offer LFOV (large field of view) cube sets compatible with Nikon Eclipse Ti2 microscopes. Please contact us for more information.
Set Components

AF01-535/40-25

FL-426386

Each
• Tavg > 93% 515 – 555 nm
• Center Wavelength of 535 nm and GMBW of 40 nm
• FWHM of 43.5 nm

FL-426386

AF01-584/40-25

FL-426477

Each
• Tavg > 93% 564 – 604 nm
• Center Wavelength of 584 nm and GMBW of 40 nm
• FWHM of 44 nm

FL-426477

AF560-Di01-25x36

FL-429439

Each
  • Dichroic Beamsplitter with edge at 560 nm
  • Ravg > 98% 490 – 555 nm
  • Tavg > 93% 564 – 680 nm
  •  Flatness / RWE: Standard Epi-fluorescence

Custom sizing delivery confirmed ARO (sizing fee applies).

FL-429439

Optical Specifications Value
Blocking Avant filters have blocking far exceeding OD 5 as needed to ensure a black background, even when using modern low-noise CCD cameras. The blocking is optimized for microscopy applications using our exclusive SpecMakerâ„¢ fluorescence filter design.
General Filter Specifications Value
Optical Damage Rating Testing has proven to show no signs of degradation when exposed to at least 6.0 W of power from an unfiltered xenon arc lamp over a 25 mm diameter (corresponding to 1.2 W/cm2) for over 500 hours.
Microscope Compatibility Avant filters are available to fit Leica, Nikon, Olympus, Zeiss, and Aperio microscopes.
Physical Filter Specifications   Value
Scratch-Dig 60-40
Orientation Arrow on ring indicates preferred direction of propagation of light.
Dichroic Orientation Reflective surface marked with part number - Orient in direction of incoming light

Avant-Cy3-ZHE

S-430998 / 0

Out of Stock Backordered In Stock

Avantâ„¢ single-band filter set, optimized for Cy3â„¢, Alexa Fluor 555 and other like fluorophores

High-performance filter set for high-end applications. Ideal for use with: Cy3™, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-OMF

S-430999 / 0

Out of Stock Backordered In Stock

Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores

High-performance filter set for high-end applications. Ideal for use with: Cy3â„¢, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-OFF

S-431317 / 0

Out of Stock Backordered In Stock

Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores

High-performance filter set for high-end applications. Ideal for use with: Cy3â„¢, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-NQF

S-431318 / 0

Out of Stock Backordered In Stock

Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores

High-performance filter set for high-end applications. Ideal for use with: Cy3â„¢, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-ZHE-ZERO

S-434101 / 0

Out of Stock Backordered In Stock

Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy3™, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-NTE-ZERO

S-434137 / 0

Out of Stock Backordered In Stock
Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy3™, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-OMF-ZERO

S-434158 / 0

Out of Stock Backordered In Stock

Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy3™, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-OFF-ZERO

S-434660 / 0

Out of Stock Backordered In Stock

Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy3™, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-NQF-ZERO

S-434661 / 0

Out of Stock Backordered In Stock
Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores. High-performance filter set for high-end applications. Ideal for use with: Cy3™, Alexa Fluor 555, and orange fluorophores

Avant-Cy3-NTE

S-429886 / 0

Out of Stock Backordered In Stock

Avant™ single-band filter set, optimized for Cy3™, Alexa Fluor 555 and other like fluorophores

High-performance filter set for high-end applications. Ideal for use with: Cy3â„¢, Alexa Fluor 555, and orange fluorophores

1 of 1

TopicDescription
Cleaning Optical FiltersInstructions for cleaning hard coated optical filters
Filter ReliabilityCompares the performance and reliability of hard coated filters to traditional soft-coated filters and provides information about the testing standards for Semrock filters
Working with Optical Density Tables to describe the relationship between OD and transmission with tips for quickly calculating OD
What is Pixel Shift, and how does the Semrock ZERO option help? Why Pixel Shift degrades multicolor fluorescence imaging performance, and how the ZERO™ option mitigates this for Avant and BrightLine filter sets.
Optimized – Filter set is specifically optimized for that fluorophore.
Compatible – Should result in nearly ideal performance in most situations.
Acceptable – Actual performance is dependent on specific experimental conditions.
Fluorophore Peak Excitation Wavelength(nm) Peak Emission Wavelength(nm) Compatibility Display on Plot above
Alexa Fluor® 555 553 565
ATTO 550 553 576
Cy3â„¢ 554 566
